12″x12″x2″ Large Size Alumina Ceramic Foam Filter Plate for Filtration
12″x12″x2″ Large Size Alumina Ceramic Foam Filter Plate for Filtration
|
Dimension (mm) |
Dimension (inch) |
Pouring rate (kg/s) |
Filtration capacity (ton) |
|
178*178*50 |
7*7*2 |
0.2-0.6 |
5 |
|
228*228*50 |
9*9*2 |
0.3-1.0 |
10 |
|
305*305*50 |
12*12*2 |
0.8-2.5 |
15 |
|
381*381*50 |
15*15*2 |
2.2-4.5 |
25 |
|
430*430*50 |
17*17*2 |
3.0-5.5 |
35 |
|
508*508*50 |
20*20*2 |
4.0-6.5 |
45 |
|
585*585*50 |
23*23*2 |
5.0-8.6 |
60 |
|
Material |
Alumina |
|
Color |
White |
|
Pore Density |
8-60ppi |
|
Porosity |
80-90% |
|
Refractoriness |
≤1200ºC |
|
Bending Strength |
>0.6Mpa |
|
Compression Strength |
>0.8Mpa |
|
Volume-weight |
0.3-0.45g/cm3 |
|
Thermal shock resistance |
6times/1100ºC |
|
Application |
Aluminium, Aluminium alloys and other Non-ferrous alloys |
1.High hardness,high electrical resistivity and high corrosion resistance.
2.Relatively low strength and fracture toughness
3.Resistance to wear and corrosive
4.Excellent thermal stability
5.Resistance to high temperatures
6.Good chemical stability and resistance
7.Excellent thermal shock resistance
Alumina ceramic foam filter is mainly applied to the aluminum and aluminum alloys fusant filter equipment of continuous casting,half-continuous casting, gravity casting, and low pressure casting, also applied to other non-ferrous metal precision casting,gas-solid and liquid-solid separation medium, high temperature gas filter, chemical filling, sound absorbing material and catalysis carrier etc.
